Glass Curtain Wall Manufacturer

Minimalist Panoramic Facade Aesthetics
Slim aluminium mullion design creates seamless transparent facades, maximising natural light and open views. Clean contemporary look perfect for modern commercial and luxury residential architecture.
Thermally Broken Anti-Condensation Energy Saving Structure
PA66 thermal break barrier eliminates thermal bridge. Reduces heat loss in cold climates (Canada, Northern USA, Europe) and blocks solar heat gain in hot Australian summers, prevents surface condensation.
High Structural Safety & Wind Pressure Resistance
Engineered aluminium framing system, calculated for local wind speed, seismic and snow load requirements. Stable for high-rise and coastal cyclone zones, no deformation under extreme weather.
All-Weather Corrosion & UV Resistance
Optional PVDF fluorocarbon coating / premium powder coating. Salt-spray resistant, fade-proof and UV stable, well suited for Australia coastal, humid and harsh outdoor environments.
High-Performance Insulated Glazing Options
Double / triple tempered Low-E insulated glass with argon gas fill. Excellent solar control, sound reduction and thermal performance, lowering HVAC running costs year-round.
Multiple System Types & Full Customisation
Stick, unitised, semi-unitised, point-supported spider glass curtain wall available. Custom frame colour, glass tint, opening casement vents, mullion width and panel size.

Product Name： Thermally Broken Aluminium Glass Curtain Wall / Facade Glazing System

Frame Material： High-grade extruded aluminium alloy + PA66 nylon thermal break strip

System Type: Stick Curtain Wall, Unitised Curtain Wall, Semi-unitised, Point-supported Spider Glass Curtain Wall

Glass Option: Double / Triple Tempered Insulated Glass, Low-E, Argon gas filled; clear, tinted, frosted, silk-screen glass

Glass Thickness: 6+12A+6mm, 8+12A+8mm, triple glazing custom

Surface Finish: PVDF Fluorocarbon Coating, Architectural Powder Coating, Anodised; full RAL colour range

U-Value Range: 1.0 ~ 2.4 W/(m²·K) (depends on glass configuration)

Sound Insulation: 34–48dB

Performance Test: Air infiltration, water penetration, wind load, structural safety

Compliance Standard: AS/NZS (AU), ASTM (US), CE (EU)

Custom Items: Panel size, mullion profile, opening vents, glass type, surface colour

Application: Luxury Villa Facade, Office Building, Hotel, Shopping Mall, Commercial High-rise
